PHOTOMETER SDM 6 WITHOUT PRINTER
Guaranteed safe payment
PHOTOMETER SDM 6 WITHOUT PRINTER is a veterinary product designed to accurately determine semen concentration and calculate doses for various types of livestock. It provides fast and reliable results through a digital interface and is used under the supervision of a veterinarian in semen processing laboratories.
Large touchscreen for intuitive operation and clear digital display of sperm concentration in billions per milliliter.
Automatic calculation of diluent volume and number of doses based on measured concentration.
Serial interface for easy data transfer to external systems.
Calibration programs for measuring semen concentration in cattle, pigs, sheep/goats, and horses.
LED light source for stable illumination and low maintenance.
Uses 10 mm macro cuvettes for sample measurement.
Electrical connection: 110–230 V, 50–60 Hz.
Operates via a touchscreen interface; the sample is placed in a 10 mm macro cuvette, and measurement is completed in about two seconds.
The device automatically calculates the dose and diluent volume.
A qualified veterinarian should determine the dosage and usage parameters based on species, body weight, and clinical condition.
Optional accessories include a control cuvette set (4 pieces), macro cuvettes (100 per pack), NaCl 0.9% solution (1 liter), NaCl solution dispenser, and micropipette (10–100 µl).
Main Benefits
Quick analysis—approximately two seconds per sample, enabling efficient workflow.Large touchscreen for intuitive operation and clear digital display of sperm concentration in billions per milliliter.
Automatic calculation of diluent volume and number of doses based on measured concentration.
Serial interface for easy data transfer to external systems.
Calibration programs for measuring semen concentration in cattle, pigs, sheep/goats, and horses.
Specifications
Spectral range: 430–680 nm with a 546 nm filter.LED light source for stable illumination and low maintenance.
Uses 10 mm macro cuvettes for sample measurement.
Electrical connection: 110–230 V, 50–60 Hz.
Usage Instructions
Designed for determining semen concentration and calculating doses in cattle, pigs, sheep/goats, and horses.Operates via a touchscreen interface; the sample is placed in a 10 mm macro cuvette, and measurement is completed in about two seconds.
The device automatically calculates the dose and diluent volume.
A qualified veterinarian should determine the dosage and usage parameters based on species, body weight, and clinical condition.
Package Size
Device without printer (reference 12300/0008).Optional accessories include a control cuvette set (4 pieces), macro cuvettes (100 per pack), NaCl 0.9% solution (1 liter), NaCl solution dispenser, and micropipette (10–100 µl).
